Die Coat Flat Spray Gun

DIE COAT FLAT PATTERN SPRAY GUN



High performance Die Coat Spray gun with high transfer efficiency. Used for spraying fine spray  with minimum overspray, bounce back,
It has very small nozzle. Input of Air & Fluid both at from one place,for better accuracy.

Continuous spraying can be achieved by feeding fluid material
by pressure feed container. This gun is light weight, Fluid path is Stainless Steel.

Air Cap of Nozzle is having special arrangement for spraying
Flat pattern.

Technical Specification :



1. Model                           : DIE COAT FLAT
2. Type                             : Pressure
3. Std. Nozzle                   : 0.5 mm
4. Operating Air Pressure : 1-2 Kgf/cm2
5. Air Consumption           : 60 L/Min.
6. Fluid Output                  :  35 Ml/Min.
7. Pattern Width                :  1-4 inch.

8. Air Inlet                          : 6 mm
9. Paint Inlet                      :  6 mm
10. Weight of the Gun       :  160 gm.
