Suction Cup Feed Spray Gun W 106S
Product Code : 1009
Price And Quantity
- Minimum Order Quantity
- 1 Piece
- Price
- 6,750 INR
Product Specifications
- Color
- Grey
- Usage
- Industrial
- Weight
- 350 Grams (g)
- Size
- 1.0 /1.3 / 1.5 mm
- Product Type
- Suction Cup Feed Spray Gun
- Type
- Suction Feed Type
Product Description
SUCTION FEED SPRAY GUN
Model : W 106S
This gun is having paint feeding cup from the bottom side of the gun.
Paint gets sucked due to venturi action of compressor air.
Centrally balanced suction feed cup enables painters to operate gun easily
from bottom side of the jobs without interruption of cup.
Aluminium cup ensures rigid handling during operation of painting.
TECHNICAL SPECIFICATION :
1. Type : Suction Feed Type
2. Nozzle : 1.0 /1.3 mm / 1.5 mm
3. Suction Cup : Aluminium.
4. Cup Capacity : 500 ml.
5. Air Pressure : 2-4 Kgf/cm2.
6. Air Consumption : 115 LPM.
7. Fluid Output : 270 Ml.
8. Pattern Width : 310 MM.
9. Air Inlet : 1/4 " BSP.
10 Fluid Inlet : 1/4 " BSP.
11 Weight of Gun : 350 Gms.
